| Engine | |
|---|---|
| Model | KLX150BF |
| Engine Type | Air cooled, single cylinder |
| Displacement | 144 cm³ |
| Bore X Stroke | 58.0 x 54.4 mm |
| Compression Ratio | 9.5:1 |
| Valve System | SOHC, 2 valves |
| Fuel System | Keihin NCV24 |
| Ignition | DC-CDI |
| Starting | Electric |
| Transmission | 5-speed |
| Clutch | Wet multi-disc, manual |
| Frame | |
|---|---|
| Type | Perimeter, box-section, high-tensile steel |
| Wheel Travel Front | 175 mm |
| Wheel Travel Back | 192 mm |
| Tyre | |
|---|---|
| Front | 2.75-21 45P |
| Rear | 4.10-18 59P |
| Suspension | |
|---|---|
| Front | 33mm telescopic fork |
| Rear | Uni-Trak rear, single gas-shock with 5-way preload adjustability |
| Brakes | |
|---|---|
| Front | Single 240 mm petal disc with twin piston caliper |
| Rear | Single 190 mm petal disc, with a single-piston calliper |
| Dimensions | |
|---|---|
| L x W x H | 2,070 x 950 x 1,155 mm |
| Wheelbase | 1,340 mm |
| Ground Clearance | 295 mm |
| Seat Height | 870 mm |
| Curb Mass | 118 kg (includes full fuel tank, all fluids at optimum levels) |
| Fuel Capacity | 6.9 litres |
| Performance | |
|---|---|
| Colour/s | Ebony |
| Warranty | 24 Months Unlimited Kilometres |
