| Engine | |
|---|---|
| Model | VERSYS-X 300 |
| Engine Type | Liquid-cooled, 4-stroke Parallel Twin |
| Displacement | 296 cm³ |
| Bore X Stroke | 62 x 49 mm |
| Compression Ratio | 10.6:1 |
| Valve System | DOHC, 8 valves |
| Fuel System | Fuel injection: 32 mm x 2 |
| Ignition | Digital |
| Starting | Electric |
| Transmission | 6-speed, return |
| Final Drive | Chain |
| Primary Reduction Ratio | 3.087 (71/23) |
| 1ST | 2.714 (38/14) |
| 2ND | 1.789 (34/19) |
| 3RD | 1.409 (31/22) |
| 4TH | 1.160 (29/25) |
| 5TH | 1.000 (27/27) |
| 6TH | 0.857 (24/28) |
| Final Drive Reduction Ratio | 3.286 (46/14) |
| Clutch | Wet multi-disc, manual |
| Frame | |
|---|---|
| Type | Tubular, diamond |
| Wheel Travel Front | 130 mm |
| Wheel Travel Back | 148 mm |
| Tyre | |
|---|---|
| Front | 100/90-19M/C 57S |
| Rear | 130/80-17M/C 65S |
| Caster (Rake) | 24.3° |
| Trail | 108mm |
| Steering Angle (Right/Left) | 40° / 40° |
| Suspension | |
|---|---|
| Front | 41 mm telescopic fork |
| Rear | Bottom-Link Uni-Trak, gas-charged shock and adjustable preload |
| Brakes | |
|---|---|
| Front | Single 290 mm petal disc. Caliper: Single balanced actuation dual piston |
| Rear | Single 220 mm petal disc. Caliper: Dual piston |
| Dimensions | |
|---|---|
| L x W x H | 2,170 x 860 x 1,390 mm |
| Wheelbase | 1,450 mm |
| Ground Clearance | 180 mm |
| Seat Height | 815 mm |
| Curb Mass | 175 kg |
| Fuel Capacity | 17 litres |
| Performance | |
|---|---|
| Max Power | 29.3 kW {40 PS} |
| Max Power With RAM Air | 11,500 rpm |
| Maximum Torque | 25.7 N.m {2.6 kgƒ·m} / 10,000 rpm |
| Colour/s | CANDY LIME GREEN/METALLIC FLAT SPARK BLACK |
